Product Description
-
H.265/ H.264 dual-stream video compression
-
All channel 1080N Non-Realtime Recording
-
Support AHD, TVI,CVI, CVBS, IP Video input
-
HDMI / VGA simultaneous video output
-
Support 2 SATA HDD up to 16TB, 2 USB2.0
-
Mobile Software: cMOB-20
-
CMS Software: CVMS-2000
Product Specification
|
Brand |
CP PLUS |
|
Product Type |
DVR |
|
Product Code |
CP-VRA-2K3216-H |
|
Processor |
High performance embedded microprocessor |
|
Operating System |
Embedded LINUX |
|
User Interface |
GUI |
|
Video Output |
1 HDMI, 1 VGA |
|
Video Recording |
32Ch. 1080N@15fps |
|
Video Display Split |
1/4/8/9/16/25/32 |
|
Video Channel |
32 Ch. |
|
Audio Output |
1 channel |
|
Audio Channel |
16 Ch. |
|
Alarm Input |
8 Channel |
|
Alarm Output |
1 Channel |
|
Smart Phone |
iPhone, iPad, Android |
|
Hard Disk |
2 SATA port, up to 16TB |
|
Hdd Management |
HDD Storage, Network Storage |
|
Recording Mode |
Manual>Alarm>Motion detection>Timing |
|
Search Mode |
Search by Time/Calendar/Event/Channel |
|
Backup Mode |
Network, USB, SATA |
|
Playback |
16/8 Ch. |
|
Ethernet |
10/100/1000Mbps Ethernet port, 1 RJ45 port |
|
Interface Ports |
2 USB 2.0, 1 RS485, 1 RS232 |
|
Protocols |
HTTP, TCP/IP, UDP, IPV4, UPNP, RTSP, SMTP, NTP, DHCP, DNS, FTP, P2P, ONVIF, CGI |
|
Power Supply |
12V/4A |
|
Power Consumption |
<10W(Without HDD) |
|
Working Temp |
0 °C - 55 °C, 10% -90% RH |
|
Dimension |
440mm(L) x 290mm(W) x 50mm(H) |
|
Weight |
3KG |
|
Warranty |
As Per Manufacturer Terms And Conditions |
