The 600 watt pure sine inverter charger, now available for purchase on Appliance Guys, is a sophisticated system that combines an inverter, battery charger, and AC auto-transfer switch. Conforming to UL 458 standards, it boasts a peak DC and AC conversion efficiency of 80%. This advanced inverter charger features power factor corrected, multi-stage charging, and pure sine wave output with high surge capability. It’s suitable for backup power or renewable energy applications, with AC/Battery priority and auto generator start functionality. It can extract maximum power from external sources with minimal battery cycles. The overload capacity is 300% of continuous output for up to 20 seconds.
Appliance Guys Exclusive Benefits:
- Lifetime Phone Support: Expert assistance always within reach.
- Open 7 Days a Week: Convenience tailored to your schedule.
- Price Match Guarantee: Shop confidently, knowing you're getting the best deals.
Features
Features
- 600 watt low frequency inverter – ETL listed to UL 458 standards
- 1800 watt surge for 20 seconds – 300% surge capability
- AC Input Cable
- GFCI outlet
- Conformal Coated for Marine Applications
- Multi Stage Smart Charger 20 Amp charges GEL, Lead, AGM, Lithium
- Remote Panel Available
- Auto Frequency Detect From AC Input
- Less than 10msec Typical Transfer Time
- Selectable 25W power save mode (hibernation)
- 7 Battery Type Settings for Charger
- Automatic transfer switch
Specifications
Specifications
Output Specifications:
- Continuous Output Power: 600 Watts
- Surge Rating: 1800 Watts (20 Seconds)
- Output Waveform: Pure Sine/Same as input (Bypass Mode)
- Output Voltage: 120Vac
- Nominal Efficiency: 80% (Peak)
- Line Mode Efficiency: >95%
- Output Frequency: 50Hz ± 0.3Hz / 60Hz ± 0.3Hz
- Typical Transfer Time: 10ms (Max)
- THD: <10%
Input Specifications:
- Nominal Input Voltage: 12.0Vdc
- Minimum Start Voltage: 10.0Vdc
- Low Battery Alarm: 10.5Vdc-11.0Vdc
- Low Battery Trip: 10.0Vdc-10.5Vdc
- High Voltage Alarm: 16.0Vdc
- Low Battery Voltage Restart: 13.3Vdc
- Low Battery Voltage Recover: 13.0Vdc
- Idle Consumption: <<25W – depending on search mode
Charger Specifications:
- Output Voltage: Depends on battery Type
- Charger Rate: 20A
- Over Charge Protection Shutdown: 15.7V
- Selectable Charge setting based on battery type
- Adjustable charge current off-20%-100%
- Four Stage Smart Charger
- Bypass: 7amps
- Low voltage trip: 8090V /-4%
- Low voltage trip: 90100V /-4%
- High voltage trip: 140V /-4%
- High voltage re engage: 135V /-4%
- Max input AC voltage: 150
Dimensions:
Dimensions:
Unit Size:
- Length: 14.75 inches
- Width: 7 inches
- Height: 5.5 inches
Shipping Size:
- Length: 17 inches
- Width: 9.75 inches
- Height: 8.5 inches
Weight:
- Unit Weight: 18 lbs
- Shipping Weight: 20 lbs
