At Aims Power, We’re Passionate About Designing And Developing Off-grid And Renewable Energy Solutions.
Built with a 48 volt DC input, this inverter performs with very little power loss. Users receive a notable increase in efficiency in large systems when compared to using 12 or 24 volts, which can be an attractive feature for sustainability lovers looking to live as efficiently as possible.
The most common use for this inverter is emergency backup power in homes, business and recreation locations. You’ll always be prepared for the next power outage with access to 10000 watts of continuous power and 30,000 watts of surge (for up to 20 seconds).
See Features Below:
-
10000 watt low frequency inverter 110/220Vac Split Phase
-
30000 watt surge for 20 seconds -3x surge capability
-
Battery Priority Selector
-
Terminal Block
-
Marine Coated and Protected
-
Multi Stage Smart charger 100 Amp charges GEL, Lead, AGM, Lithium
-
Remote panel available
-
10msec typical transfer time
-
Selectable 25W power save mode (hibernation)
-
8 battery charger settings
-
Automatic transfer switch
Specifications
| Continuous Output Power | 10000 Watts |
|---|---|
| Surge Rating | 30000 Watts (20 Seconds) |
| Output Waveform | Pure Sine/Same as input (Bypass Mode) |
| 100-110-120Vac / 220-230-240Vac | |
| Nominal Efficiency | >88% (Peak) |
| Line Mode Efficiency | >95% |
| Output Frequency | 50Hz /- 0.3Hz / 60Hz /- 0.3Hz |
| Typical Transfer Time | 10ms (Max) |
| THD | < 10% DC |
| Ambient operating temperature | 14°F to 122°F (-10°C to 50°C) |
| Input Specifications | |
| Nominal Input Voltage | 48.0Vdc |
| Low Battery Alarm | 42.0Vdc-44.0Vdc |
| Low battery Trip | 40.0Vdc-42.0Vdc |
| High Voltage Alarm | 64.0Vdc |
| Low battery Voltage Restart | 62.0Vdc |
| Idle Consumption | 150 Watts |
| Power Saver Mode Idle Consumption | 35 Watts |
| Charger Specifications | |
| Output voltage | Depends on battery Type |
| Charger Rate | 100A |
| Dimensions | |
| Unit Weight | 145.5 lbs. |
| Unit Size L x W x H | 23.3 x 16.3 x 7.9 inches |
| Shipping Weight | 190 lbs. |
| Shipping L x W x H 30 x 21.25 x 15.25 inches |
